COMPRESSTOME® VF-800-0Z

Large Diameter Vibrating Microtome

Our Compresstome® VF-800-0Z tissue slicer is a fully-automated large diameter vibrating microtome capable of embedding large organs or multiple samples simultaneously for preclinical uses. Experimental applications include:

High-throughput tissue sectioning
Slice cultures for drug screening
Large diameter samples (i.e., primate brain)

Key Features of the VF-800-0Z Vibratome

User-friendly controls: Fully integrated control box has intuitive control parameters for controlling tissue sectioning

Compact Design: Small design for a vibratome that can section large tissues

Ultra precision: custom made blades for ultra precision of large tissues

Large cutting area: Can section samples up to 100 mm, or multiple samples

Durable: Equipped with a powerful, cordless motor for quiet and durable operation

What Sets the VF-800-0Z Apart

Healthy tissue sections from large organs

The VF-800-0Z excels at slicing large, delicate specimens, such as whole brains from monkeys or human organs like the heart and liver, making it ideal for your large organ research.

Make hundreds of tissue sections fast

Designed to section many tissues at once, this vibratome enables precise sectioning for drug screening studies, including liver and kidney slices critical for metabolism and toxicity testing.

Full Automation for Consistent and Reliable Performance

The VF-800-0Z ensures reproducible tissue sections across a wide range of applications, delivering consistent results for long-term studies and diverse experimental needs.

VF-800-0Z Technical Specifications

Advance speed

0-7 mm/s, adjustable

Return speed

10 mm/s, fixed

Vibration frequency

0-20 Hz, adjustable

Vibration amplitude

0.9 mm, fixed

Z-Axis vibration

<4 µm

Compatible cutting blades

Tungsten carbide blades

Cutting angle

30 degrees, fixed

Thickness adjustment

Automatic, digital

Micrometer resolution

1 µm

Maximum tissue diameter

100 mm (Want bigger? Talk to us.)

Maximum tissue length

90 mm

Slice thickness range

40 µm to 2000 µm

Cutting modes

Single or continuous, selectable

Buffer tray size (L x W x H)

290 x 160 x 40 mm

Power source

Input - 100-240V AC, 50-60 Hz Output - 12V, 1.5A DC

Power consumption

18 W

Dimensions (L x W x H)

350 x 380 x 380 mm

Weight

15 kg

Key Application Areas

Experiments

Electrophysiology

Immunohistochemistry

Histopathology

High-throughput sectioning

Large sample (whole organ) sectioning

Precision-cut tissue slices (PCTS)

Imaging

Electron microscopy

Genetic Sequencing (Single-Cell Isolation)

In-situ hybridization

Material & Bio-engineering (Polymers)

Organoids

Organotypic slice culture

Plant research

Organ Systems

Brain (fixed)

Brain (live or acute)

Animal Models

Researchers Trust Precisionary

Dr. Claudia Loebel

University of Michigan

“Very satisfied with the customer support before and after purchase. The Compresstome was shipped within just a couple weeks and customer support responded within 24 h whenever we had issues or questions. In addition, the training videos and zoom calls were extremely beneficial to get started.”

Dr. Ben Richardson

Southern Illinois University

Our lab made the switch from standard vibratome-prepared ex vivo brain slices to compresstome-prepared slices a few years ago. Combining the compresstome with modified slicing solutions has allowed us to generate electrophysiological data that would have otherwise likely not been possible from the cerebellum to difficult brain areas to slice, like the locus coeruleus and thalamic reticular nucleus. Not only is the product exceptional, but the Precisionary is also so supportive and invested in helping us achieve our experimental goals.
